S5LS20216ASZWTQQ1 Microcontroller IC 16/32B 2MB FLASH 337NFBGA

Product Categories
SZ ADE Electronics Co., Ltd
Contact Now

S5LS20216ASZWTQQ1 Microcontroller IC 16/32B 2MB FLASH 337NFBGA

Brand Name : original

Model Number : S5LS20216ASZWTQQ1

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T, L/C

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Mfr : Texas Instruments

Series : Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R

Package : Tray

Product Status : Not For New Designs

Digi-Key Programmable : Not Verified

Core Processor : ARM® Cortex®-R4F

Core Size : 16/32-Bit

Speed : 160MHz

Contact Now

S5LS20216ASZWTQQ1 Current Sense Resistors Ic Mcu 16/32b 2mb Flash 337nfbga
ARM® Cortex®-R4F Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R Microcontroller IC 16/32-Bit 160MHz 2MB (2M x 8) FLASH 337-NFBGA (16x16)

Specifications of S5LS20216ASZWTQQ1

TYPE DESCRIPTION
Category Integrated Circuits (ICs)
Embedded
Microcontrollers
Mfr Texas Instruments
Series Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R
Package Tray
Product Status Not For New Designs
Digi-Key Programmable Not Verified
Core Processor ARM® Cortex®-R4F
Core Size 16/32-Bit
Speed 160MHz
Connectivity CANbus, EBI/EMI, LINbus, SCI, SPI, UART/USART
Peripherals DMA, POR
Number of I/O 115
Program Memory Size 2MB (2M x 8)
Program Memory Type FLASH
EEPROM Size -
RAM Size 160K x 8
Voltage - Supply (Vcc/Vdd) 1.35V ~ 1.65V
Data Converters A/D 24x12b
Oscillator Type External
Operating Temperature -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 337-LFBGA
Supplier Device Package 337-NFBGA (16x16)
Base Product Number S5LS20216

FEATURES of S5LS20216ASZWTQQ1

• High-Performance Automotive Grade
Microcontroller for Safety Critical Applications
– Dual CPUs running in Lockstep
– ECC on Flash and SRAM
– CPU and Memory BIST (Built-In Self Test)
– Error Signaling Module (ESM) w/ Error Pin
• ARM® Cortex™-R4F 32-Bit RISC CPU
– Efficient 1.6 DMIPS/MHz with 8-stage pipeline
– Floating Point Unit with Single/Double Precision
– Memory Protection Unit (MPU)
– Open Architecture With Third-Party Support
• Operating Features
– Up to 160-MHz System Clock
– Core Supply Voltage (VCC): 1.5 V
– I/O Supply Voltage (VCCIO): 3.3 V
• Integrated Memory
– 1M-Byte or 2M-Byte Flash with ECC
– 128K-Byte or 160K-Byte RAM with ECC
• Multiple Communication interfaces including
FlexRay, CAN, and LIN
• NHET Timer and 2x 12-bit ADCs
• External Memory Interface (EMIF)
– 16bit Data, 22bit Address, 4 Chip Selects
• Common TMS470/570 Platform Architecture
– Consistent Memory Map across the family
– Real-Time Interrupt (RTI) OS Timer
– Vectored Interrupt Module (VIM)
– Cyclic Redundancy Checker (CRC, 2 Channels)
• Direct Memory Access (DMA) Controller
– 32 DMA requests and 16 Channels/ Control
Packets
– Parity on Control Packet Memory
– Dedicated Memory Protection Unit (MPU)
• Frequency-Modulated Zero-Pin Phase-Locked
Loop (FMzPLL)-Based Clock Module
– Oscillator and PLL clock monitor
• Up to 115 Peripheral IO pins
– 16 Dedicated GIO - 8 w/ External Interrupts
– Programmable External Clock (ECLK)

Applications of S5LS20216ASZWTQQ1

Packages Supported
– 144-Pin Quad Flat Pack (PGE) [Green]
– 337-Pin Ball Grid Array (ZWT) [Green]
• Community Resources
– TI E2E™ Online Community

Environmental & Export Classifications of S5LS20216ASZWTQQ1

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
