LM22676MRE-5.0 / NOPB Switching Regulator IC 5V 1 Output 3A 8-Power SOIC
Features of LM22676MRE-5.0/NOPB
Wide Input Voltage Range: 4.5 V to 42 V
Internally Compensated Voltage Mode Control
Stable with Low ESR Ceramic Capacitors
120 mΩ N-Channel MOSFET PFM Package
100 mΩ N-Channel MOSFET PSOP-8 Package
Output Voltage Options:
-ADJ (Outputs as Low as 1.285 V)
-5.0 (Output Fixed to 5 V)
±1.5% Feedback Reference Accuracy
Switching Frequency of 500 kHz
–40°C to 125°C Operating Junction Temperature Range
Precision Enable Pin
Integrated Boot-Strap Diode
Integrated Soft-Start
LM22676Q is an Automotive Grade Product that is AEC-Q100 Grade 1 Qualified (–40°C to
+125°C Operating Junction Temperature)
Product Attributes of LM22676MRE-5.0/NOPB
| TYPE | DESCRIPTION |
| Series | SIMPLE SWITCHER® |
| Product Status | |
| Function | |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | |
| Voltage - Input (Min) | |
| Voltage - Input (Max) | |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | |
| Current - Output | 3A |
| Frequency - Switching | |
| Synchronous Rectifier | |
| Operating Temperature | |
| Mounting Type | |
| Package / Case | 8-PowerSOIC (0.154", 3.90mm Width) |
| Supplier Device Package | |
| Base Product Number | LM22676 |
Applications of LM22676MRE-5.0/NOPB
Industrial Control
Telecom and Datacom Systems
Embedded Systems
Conversions from Standard 24 V, 12 V and 5 V Input Rails
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
